TECHNICAL SPECIFICATIONS

Model Number: AC-10000E AC-10000H

Voltage / Frequency 115V / 60Hz

Power Consumption for cooling” 909W / 8.3A

Power Consumption for heating” NIL 830W / 7.6A

Air Volume (Maximum Speed) 300 m

Dehumidification Capacity 2.1 pints/hr (1 L/hr)

Compressor Type Rotary

Refrigerant Type R-410A

Number of Fan Speeds 2

Timer 1 ~ 12 hours

Exhaust Pipe Dimensions Ø4.72” X 59.06” (Ø120x1500 mm)

Product Weight 50.7 lbs (23kg)

Product Dimensions (W x D x H)

12.2” x 13.8” x 28”

( 310 x 350 x 710 mm )

ADDITIONAL REMARKS:

1. The data marked with '*' may vary for technical reasons; for more accurate data, please refer

to the rating label found on the back of the unit.

2. Measuring condition for the above specifications:

Cooling –DB = 95°F (35°C), WB= 82.94°F (28.3° C)

Heating – DB= 68°F (20°C) , WB= 59°F (15°C)

* D.B. = dry bulb temperature = room temperature

* W.B. = wet bulb temperature = relative humidity
